LandVac Vacuum Glass Insulated LOW-E Glass Noise-Control Glass
U-Value as low as 0.4W/(Square meters·K). A 8.3 mm thick LandVac has better thermal insulation effect than a 1.5m thick brick wall.
With its weighted sound reduction index exceeding 36dB, LandVac makes rooms in downtown as quiet as a library.
Free of condensation even when the temperature falls below -70 °C. Ultra-low dew point allows LandVac to maintain exceptional transparency.
Surface stress and granularity meet tempered glass standards; wind resistance up to ±7200Pa.
ANSI Z97.1-2015 & CPSP 16CFR 1201(1977); ATI North America; ift Germany; RoHS European Union standards.
LandVac® is an all-new generation tempered vacuum insulated glass. Using exclusive low-temperature sealing technology, the product has outstanding features in thermal and sound insulation while retaining the strength and safety of the glass at a high level. LandVac leads the trend of glass applications in green buildings and upscale home appliances.
| Product Type | Structure | Thickness (mm) |
|---|---|---|
| LandVac | 4TL+0.3V+4T | 8.3 |
| Triple Glazing (LandVac Plus) | 4T+12A+4TL+0.3V+4T | 24.3 |
| Product Type | U-value (W/m²K) | SHGC | SC | Sound Isolation (dB) |
|---|---|---|---|---|
| LandVac | 0.48 | 0.49 | 0.56 | 39 |
| Triple Glazing | 0.42 | 0.45 | 0.52 | 42 |
* T-Tempered clear glass; TL-tempered Low-E glass; V-vacuum space; A-air space. Data for reference based on ASHRAE standards.
Tempered Safety Glass: Surface stress exceeds 90MPa, meeting safety glass standards perfectly. Noise Reduction: Effectively blocks medium and low-frequency noises like traffic and construction. Ultimate Dewpoint: Interior glass surface remains free of condensation even when the outdoor temperature falls to -40 °C.
LandVac tempered vacuum insulated glass has been approved by authoritative third parties. Results show that the thermal insulation performance is up to the highest level of national standards (Level 10) and sound insulation performance reaches Level 4.
