MGW Glass
MGW Glass
| Specifications | Parameter Range | Applicable Scenarios | Thickness / Transmittance | Power Output |
|---|---|---|---|---|
| Home | 1200×600mm / 1600×800mm | Home Roofs / Balcony Railings | 10-12mm / 10%-60% | 100W-300W/unit |
| Commercial | 2400×1200mm / 3000×1500mm | Factory Walls / Large-Scale Plants | 22mm / 10%-60% | 500W-1000W/unit |
| Custom | 1000-4000mm available | Special Curtain Walls / Landscapes | 6-20mm / 10%-60% | Calculated by size |
| Our R&D center expects battery conversion rates to reach 19% by 2026. We offer 24/7 consultation for residential, industrial, and commercial photovoltaic systems. | ||||
Our cadmium telluride thin-film solar cells consist of five layers: glass substrate, transparent conductive oxide (TCO) layer, cadmium sulfide (CdS) window layer, cadmium telluride (CdTe) absorption layer, and back contact/electrode layers.
CdTe is a direct bandgap material. Its luminous effect in weak light conditions—such as early morning, evening, snow, or haze—is significantly superior to crystalline silicon cells.
Performance remains stable at high temperatures. The temperature coefficient is roughly half that of crystalline silicon solar cells, generating more power in hot environments.
With a 1.47eV bandgap compatible with the solar spectrum, it absorbs 90% of visible light with a thickness of only 1μm. Theoretical efficiency potential reaches 28-29%.
Unlike crystalline silicon, these modules do not suffer from light-induced degradation and maintain steady output even in humid climates as they do not absorb water vapor peaks.
We are an advanced materials enterprise specializing in the R&D and production of cadmium telluride (CdTe) and perovskite thin-film solar cells. Our strategic focus includes BIPV (Building-Integrated Photovoltaics) and photovoltaic-powered consumer electronics. Our products feature customizable shapes, dimensions, and light transmittance for seamless integration with modern architecture.
