Basic Specifications
Model NO.Landvac vacuum glass
Min. Dimension300*300mm
Thickness8-11mm
Vacuum Layer0.3mm
Weight20-28 Kg/㎡
Color ChoiceClear, Ultra Clear, Dark Gray, Ocean Blue, Sapphire
ServiceCustomized Service
Specification1500*2500mm
TrademarkLandVac
HS Code7008001000
Key Advantages
🔥
Thermal Insulation: U-Value as low as 0.4W/(㎡·K). An 8.3 mm thick LandVac provides better insulation than a 1.5m thick brick wall.
🔇
Noise Reduction: Weighted sound reduction index exceeds 36dB, effectively blocking traffic and construction noise.
❄️
Free of Condensation: Remains condensation-free even below -70°C, maintaining exceptional transparency for buildings and freezers.
🛡️
Tempered Safety: Surface stress exceeds 90MPa, meeting tempered glass standards with wind resistance up to ±7200Pa.
Technical Parameters
| Product Type |
Structure |
Thickness (mm) |
| LandVac |
4TL+0.3V+4T |
8.3 |
| Triple Glazing (LandVac Plus) |
4T+12A+4TL+0.3V+4T |
24.3 |
| Product Type |
U-value (W/m²K) |
SHGC |
SC |
Sound Isolation (dB) |
| LandVac |
0.48 |
0.49 |
0.56 |
39 |
| Triple Glazing |
0.42 |
0.45 |
0.52 |
42 |
Advanced Performance
Core Technologies
Low Temperature Sealing Technology
Retains safety features of tempered glass with surface stress exceeding 90MPa, resolving the problem of glass annealing during sealing.
Flexible Edge Sealing Technology
Uses flexible materials with high resistance against thermal expansion and contraction, preventing sealing failure due to temperature differences.
High Vacuum Sealing off Technology
Sealed in a UHV chamber to maintain a consistent high degree of vacuum for outstanding durability.
Flat Sealing Technology
The seal does not protrude above the glass surface, ensuring easy transportation and an elegant look in window frames.
Wide Applications
ArchitectureWindows, doors, curtain walls, skylights, and green buildings.
Home AppliancesFreezers, wine cabinets, and display cases.
TransportationHigh-speed rail, aircraft, and vessels.
BIPVSolar photovoltaic buildings.
AgricultureModern greenhouse farming.
Manufacturing & Qualification
Frequently Asked Questions
Q1: What is the thermal insulation performance of LandVac?
LandVac features a high vacuum interspace that eliminates gas heat transfer. With Low-E coating, the U-value is reduced to 0.48 W/(m²·K), which is 2 to 4 times better than standard insulated glass.
Q2: Can LandVac prevent window condensation?
Yes. The high vacuum interspace effectively eliminates dew condensation between glass layers, keeping the interior surface clear even when outdoor temperatures fall to -40 °C.
Q3: Is this glass safe for high-rise buildings?
Absolutely. LandVac is fully tempered vacuum insulated glass. Its surface stress exceeds 90MPa, meeting safety glass standards and offering wind resistance up to ±7200Pa.
Q4: How effective is it for noise reduction?
It has a weighted sound reduction index exceeding 36dB. It is particularly effective against medium and low-frequency noises like traffic and construction sounds.
Q5: What is the life expectancy of LandVac vacuum glass?
The life expectancy exceeds 25 years, thanks to flexible edge sealing technology and built-in high-efficiency getter materials that resist material aging.
Q6: How thin is LandVac compared to triple glazing?
LandVac is significantly lighter and thinner. It is approximately one-sixth the thickness of triple-pane insulated glass and weighs about 10 kg less per square meter.
