◈ Float Glass: Ordinary float glass with a metallic coating fused to the glass at 1200ºC. The special metallic coating provides a one-way mirror effect, preserving privacy while maintaining durability.
◈ On-line Reflective Glass: Processed via Chemical Vapor Deposition (CVD) technology. Known for its durability, it can be easily cut, heat-strengthened, or toughened.
◈ Off-line Reflective Glass: Produced by Magnetron Sputtered Vacuum Deposition (MSVD). Leads to various colors and high thermal performance.
| No. | Product Name | VT | UV Trans. | Visible Light Trans. | Visible Light Refl. | Sunlight Trans. | Sunlight Refl. | Total Solar Trans. | SC | Radiance | SHGC | K (Summer) | K (Winter) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 5mm Bluestar Grey | 25% | 4.68% | 24.93% | 17.13% | 32.67% | 15.22% | 45.24% | 0.51 | 0.84 | 0.482 | 5.272 | 5.843 |
| 2 | 6mm Bluestar Grey | 20% | 3.50% | 20.82% | 14.09% | 27.39% | 12.71% | 41.83% | 0.47 | 0.84 | 0.455 | 5.243 | 5.808 |
| 4 | 4mm Ford Blue | 33% | 7.81% | 32.70% | 38.60% | 42.20% | 26.20% | 50.60% | 0.582 | 0.84 | 0.506 | - | 5.360 |
| 10 | 5mm Clear Low-E | 80% | 39.94% | 80.17% | 10.45% | 68.81% | 10.15% | 72.32% | 0.81 | 0.19 | 0.723 | 2.939 | 3.777 |
| 12 | 5mm Dark Blue | 20% | 12.07% | 23.35% | 13.46% | 43.49% | 18.44% | 52.68% | 0.59 | 0.84 | 0.546 | 5.272 | 5.843 |
